Comparc S 512 P Suitcase Wire Feeder
Comparc S 512 P Suitcase Wire Feeder
Regular price
$3,195.00 CAD
Regular price
Sale price
$3,195.00 CAD
Unit price
/
per
Couldn't load pickup availability
Compatible with Lincoln Electric, Miller, Hobart and Comparc Engine Driven Welders.
The Comparc S512 P voltage sensing MIG wire feeder is a portable, compact and lightweight solution for field MIG and Flux Core welding where an engine driven welder is available.
The S 512 P features a 2-Roll drive system utilizing popular Miller style rolls, making parts easy to find and providing reliable feeding of all wires up to 5/64". The system is packed into a Nanuk brand hard case with dual latches to provide rugged resistance to the elements.
Specifications
Number of rollers: 2
Arc Voltage range: 14 - 110 VDC
Input Circuit Capacity: 400A @ 60% duty cycle
Wire Speed: 60" - 850" per min
Wire Diameter: .023" - 5/64" (0.6mm - 2.0mm)
Features
Easy to carry and light weight
Environmentally protected pc board
Gas valve
Digital meter for voltage and current/ wire speed
Accepts spools up to 12" in diameter
Contactor
Includes drive roll set of 0.9 and 1.2mm (0.035" - 0.045')
What's Included
S 512 P Voltage Sensing Wire Feeder
Voltage sense lead
Inert gas hose
1 Set 035-045 V-Groove Drive Rolls
